Complete lineup for Marble cutting tools

There is a wide range of processes associated with marble cutting, starting from large blocks and continuing all the way to small sized tile. There are many tools suited to each distinct usage.

Marble is softer than granite but it still is a stone. As compared to metal, marble is still a very hard material. Potential modalities for cutting marble include saws, blades and cutters, all of which contain diamonds.

The "cutting" process greatly affects the efficiency of the grinding and polishing processes to follow. If the cutting is not done properly, extra work is required during the polishing process and sometimes there is no way to recover. Quality cutting tools share three indispensable characteristics: they must have a "sharp cutting edge" and a "long-lasting life" and they must enable the artisan to execute "accurate and precise cutting" without any run out.

The loud noise produced when cutting marble can be a nuisance. Some of our cutting tools have a sound deadening function to improve your work environment. This sound can be used for barometer for efficient work.

Electro-plated diamond saw blades for marble cutting are especially well suited for attaching to disc grinders. Electro-plated blades do not cause any loading since they have the largest protrusion of diamond as compared with other bonds. This characteristic also well suit to FRP (fiber-reinforced plastic).

Cutting tools for marble and travertine

marble cutting tools saw blade | For large work materials

Outer diameter
D(mm)
Backing metal thickness
H(mm)
Chip size
TxXxL(mm)
Chip amount(N)
200 3.2 4.7x9x38 14
225 16
250 3.3 16
300 3.0 4.5x9x30 24
350 18
400 32
450 3.5 36
500 40
550 44
600 3.8 5x9x30 48
650 52
700 56
750 4.3 5.5x9x30 55
800 58
850 4.7 6x9x30 61
900 5.0 6.5x9x30 64
950 7x9x30 67
1000 5.5 7.5x12x25 70
1050 7.5x12x30 73
1100 6.0 8x12x25
8x12x30
76
1150 79
1250 84
1300 6.5 8.5x12x25
8.5x12x30
88
1350 92
1400 96
1600 7.0 9x14x25
9x14x30
106
1800 9.5x14x25
9.5x14x30
120
2000 8.0 11x14x25 132
2200 136
2500 9.0 12x17x25 140
3000 11.5 15.5x20x25
15.5x20x30
160

marble diamond cutter | Stone slab, slate, decorative stone

Outer diameter
D(mm)
Backing metal thickness
H(mm)
Chip size
TxXxL(mm)
Inside diameter
C(mm)
Chip amount(N)
N
Pitch
Pmmxn
Hardness
450 3.0 4.0x8x40 26 33 90x6
110x6x6
110x6x8
CS5
CS10
CX10
CX30
500 36
550 40
600 3.5 4.5x8x40 43

marble diamond cutter type S | Stone slab, slate, decorative stone

Outer diameter
D(mm)
Backing metal thickness
H(mm)
Chip size
TxXxL(mm)
Inside diameter
C(mm)
Chip amount(N)
Pitch
Pmmxn
Hardness
450 3.2 4.0x10x40 26 33 90x6
110x6x6
110x6x8
S1
S2
500 36
550 40
600 3.5 4.5x10x40 43
650 3.5 45

marble cutting tools coping saw | For large work materials

Outer diameter
D(mm)
Backing metal thickness
H(mm)
Chip size
TxXxL(mm)
Chip amount(N) Form
350 2.2
(Silent type 2.4)
3x10x36 28 Standard
3x10x20 42 Bortz
400 3x10x36 32 Standard
3x10x20 48 Bortz
450 2.6 3.5x10x36 36 Standard
3.5x10x20 54 Bortz
500 3 4x10x36 40 Standard
4x10x20 60 Bortz
550 4x10x36 44 Standard
4x10x20 66 Bortz
600 4x10x36 48 Standard
4x10x20 72 Bortz
650 4x10x36 52 Standard
700 56

marble cutting tools rim saw cutter | For tile, marble, glass

Outer diameter
D(mm)
Segment Grit
Width
T
Height
X
Chip amount(N) Inside diameter
C(mm)
400 2.2 5 8 73.03
(50.8R)
60
80
36

Marble cutting tools electro-plated cutter | For cutting Marble, FRP(fiber-reinforced plastic)

Outer diameter D(mm) 125
Inside diameter C(mm) 20, 22
Applicable materials Marble, FRP(fiber-reinforced plastic)
Applicable machines Disc grinder
